RC Model car electronic dashboard （part）

Note: This product only supports 2S 3S 4S batteries, larger than 4S batteries
It may burn out the electronics, only these three types of batteries have data display.
Wiring:
1.
The yellow line is connected in parallel with the Y line to the gear channel, which can display the N gear
1st gear, 2nd gear, three gears. (Note: the rudder amount of the steering gear must be
Must be greater than or equal to 30%, below this value will not be displayed)
2.
The green line is connected in parallel with the Y line to the throttle channel, which can be adjusted according to the throttle
Output signal analog speed dynamic display. (Note: the maximum display
Speed 69km/h)
3.
The red wire connector jst is connected in parallel with the battery, which can display the battery
Information (eg 2S), battery level (red means low voltage, green means full battery),
Voltage information is displayed in the upper center. (Note: When the battery is displayed in red,
It needs to be charged in time to prevent the battery from over-discharging)
